Weichai 12WH17 series marine diesel engine (1150-1620kW)
weichai
Weichai 12WH17 series marine diesel engine (1150-1620kW)
Parameters Table
Type | Four-stroke, water cooled, in-line, turbocharged and aftercooled | Number of cylinders | 12 |
Bore & stroke | 170×220（mm） | Displacement | 54.48 L |
Oil consumption rate | ≤0.3 g/kW.h | Noise | ≤111dB(A) |
Minimum fuel consumption rate | ≤200 g/kW.h | Idle speed | 650±30 r/min |
Torque reserve | ≥15% | Rotation (facing the flywheel) | Counter-clockwise |
Dimensions (L×W×H) | 2256×1331×1856 (mm) | Net weight | 5300 kg |
Remark: Product parameters and model portfolio are for reference only. Please contact relevant personnel for official information on delivery time and fishing boat model portfolio.
Model Portfolio Table
Series | Model | Aspiration | Rated power kW/Ps | Speed r/min | Fuel system | Emission | Power rating |
12WH17* | 12WH17C1564-2 | TA | 1150/1564 | 1200 | HPCR | IMO Ⅱ | P1 |
12WH17C1700-5 | TA | 1250/1700 | 1500 | HPCR | IMO Ⅱ | P1 | |
12WH17C1972-5 | TA | 1450/1972 | 1500 | HPCR | IMO Ⅱ | P1 | |
12WH17C2203-5 | TA | 1620/2203 | 1500 | HPCR | IMO Ⅱ | P2 |
