WP7 series engines for excavators

weichai

Overview

Weichai WP7 series engines for loaders. Power range: 154-162kW. Euro stage IIIa emission standard. Application: 5t loaders.

Power Rating
Maximum Power				129 kW
Minimum Power				92 kW
Maximum Torque / Speed				(950-1000)/（1300-1500） N·m / r/min
Emission Standards
Emissions				Euro Stage IIIa
General
Series				WP7
Fuel				Diesel
Type				Inline 6-cylinder, four-stroke engine
Cylinder Number				6
Valve Number				4
Bore				108 mm
Stroke				136 mm

Aspiration				Turbocharged and intercooled
Compression Ratio				18:01
Combustion System				Electronically controlled high-pressure common-rail
Engine Dimensions (Approximate. Final dimensions dependent on selected options)
Length				1367 mm
Width				817 mm
Height				1050 mm
Weight - Net Dry (Basic Operating Engine Without Optional Attachments)				700 kg
Remarks: Product parameters and pictures are for reference only; subject to change without notice.

Model	Rated Power/ Speed （kW/rpm）	Maximum Torque / Speed （N·m/rpm）	Displacement （L）	Technique Route	Valve Number	Adaptable Vehicle
Model	Rated Power/ Speed （kW/rpm）	Maximum Torque / Speed （N·m/rpm）	Displacement （L）	Technique Route	Valve Number	Adaptable Vehicle
WP7G193E301	142/2000	900/1400-1500	7.47	Common rail + Turbocharger and intercooller	4	excavator
WP7G230E301	170/2000	1050/1200-1500	7.47	Common rail + Turbocharger and intercooller	4	excavator
WP7G270E301	199/2000	1200/1200-1500	7.47	Common rail + Turbocharger and intercooller	4	excavator
